Display
Panel Size (inch) : 23.8
Aspect Ratio: 16:9
Display Viewing Area (H x V) : 527.04 x 296.46
Display Surface: Non-Glare
Backlight Type: LED
Panel Type: IPS
Viewing Angle (CR≧10, H/V): 178°/ 178°
Pixel Pitch : 0.2745mm
Resolution : 1920×1080
Brightness (Typ.) : 250cd/㎡
Contrast Ratio (Typ.) : 1000:1
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Display Colors: 16.7M
Response Time: 1ms MPRT
Refresh Rate (Max) : 75Hz
Flicker-free: Yes
Aspect Ratio: 16:9
Display Viewing Area (H x V) : 527.04 x 296.46
Display Surface: Non-Glare
Backlight Type: LED
Panel Type: IPS
Viewing Angle (CR≧10, H/V): 178°/ 178°
Pixel Pitch : 0.2745mm
Resolution : 1920×1080
Brightness (Typ.) : 250cd/㎡
Contrast Ratio (Typ.) : 1000:1
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Display Colors: 16.7M
Response Time: 1ms MPRT
Refresh Rate (Max) : 75Hz
Flicker-free: Yes
Video Feature
Trace Free Technology: Yes
SPLENDID Technology: Yes
Color Temp. Selection: Yes(3 modes)
GamePlus: Yes
QuickFit: Yes (Letter/Photo/Alignment Grid)
HDCP: Yes, 1.4
VRR Technology: FreeSync™
Motion Sync: Yes
Low Blue Light: Yes
Eye Care+ Technology: Yes
SPLENDID Technology: Yes
Color Temp. Selection: Yes(3 modes)
GamePlus: Yes
QuickFit: Yes (Letter/Photo/Alignment Grid)
HDCP: Yes, 1.4
VRR Technology: FreeSync™
Motion Sync: Yes
Low Blue Light: Yes
Eye Care+ Technology: Yes
Audio Feature
Speaker: No
I/O Ports
HDMI(v1.4) x 1
VGA x 1
Earphone Jack: Yes
PC Audio Input: Yes
VGA x 1
Earphone Jack: Yes
PC Audio Input: Yes
Signal Frequency
Digital Signal Frequency : 30-83KHz (H) / 48-75Hz (V)
Analog Signal Frequency : 30-83KHz (H) / 48-75Hz (V)
Analog Signal Frequency : 30-83KHz (H) / 48-75Hz (V)
Power Consumption
Power Consumption: 16W
Power Saving Mode: <0.5W
Power Off Mode : <0.3W
Voltage: 100-240V, 50/60Hz
Power Saving Mode: <0.5W
Power Off Mode : <0.3W
Voltage: 100-240V, 50/60Hz
Mechanical Design
Tilt: Yes (+23° ~ -5°)
Height Adjustment: No
VESA Wall Mounting: 100x100mm
Kensington Lock: Yes
Antibacterial treatment: Yes
Height Adjustment: No
VESA Wall Mounting: 100x100mm
Kensington Lock: Yes
Antibacterial treatment: Yes
Dimensions (Esti.)
Phys. Dimension with Stand (W x H x D) : 541x393x185 mm
Phys. Dimension without Stand (W x H x D) : 541×322.9×48 mm
Box Dimension (W x H x D) : 603x392x130 mm
Phys. Dimension without Stand (W x H x D) : 541×322.9×48 mm
Box Dimension (W x H x D) : 603x392x130 mm
Weight (Esti.)
Net Weight with Stand: 3.38 Kg
Net Weight without Stand: 2.92 Kg
Gross Weight: 4.62 Kg
Net Weight without Stand: 2.92 Kg
Gross Weight: 4.62 Kg
Operation Temperature / Humidity
Operation temperature: 0~45 degrees C
Operation humidity : 65+/- 25%
Operation humidity : 65+/- 25%
